Gänge

8 Gänge

Frame

MATTS J. 24+; MAT aluminium; 24x2.4" max. WHS; 135x9/100x9 AST; BSA BBR

Gabel

MERIDA MATTS J. 24+; MAT aluminium; 24x2.4" max. WHS

Bremse V

Tektro M275

Bremse H

Tektro M275

Bremsscheibe V

TR-160; 160mm

Bremsscheibe H

TR-140; 140mm

Bowden

SP40

Kette

KMC Z8.3

Kurbel

MERIDA EXPERT JR; 28 ATC

Crank/Size

140 mm

Tretlager

FSA TH-7420ST, 68-118

Schaltwerk

Shimano RD-M310

Freilauf

Sunrace CSM558AU; 11-32 teeth; 8 speed; Nickel

Pedal

Marwi SP-202

Griff

MERIDA EXPERT JR

Lenker

MERIDA EXPERT JR; MAT aluminium; 620 WHB; 0 RHB

H-B Stem

MERIDA CC; MAT aluminium; 31.8 DSH; 6 ASD

H-Stem/size

60 mm

Steuerkopf

FSA NO.10P Neck15

compressor

attached

spacer

Plastic 10mm*2+5MM*2

Nabe V

KT-K68F; 100x9 WHF; 24 SPH

Nabe H

KT-K68R-8/9/10S; 135x9 WHR; 24 SPH

Felge

MERIDA JR 24+; MAT aluminium

Sattel

MERIDA EXPERT JR

Sattelklemme

MERIDA COMP QR

Sattelstütze

MERIDA COMP CC; MAT aluminium; 27.2 DSP; 0 SSB

Schalthebel

Shimano SL-M315-8

Schlauch

F.V lite

Reifen V

K1153 24*2.35

Reifen H

K1153 24*2.35
